Decoding BookMyShow: Understanding and Implementing Server Driven UI

April 13, 2025 (1d ago)

Samyak Jain

Samyak Jain

Introduction

Have you ever wondered how complex applications like BookMyShow maintain a consistent user experience across platforms while enabling rapid updates without requiring app releases? The answer lies in Server-Driven UI (SDUI), a powerful architecture that's revolutionizing how we build modern applications.

In this blog post, I'll walk you through my journey of reverse-engineering BookMyShow's API to understand their SDUI implementation. The result is Decode BookMyShow, an open-source project that showcases how to build a flexible SDUI framework.

Table of Contents

What is Server-Driven UI?

Server-Driven UI is an architectural pattern where the UI layout, components, and their properties are defined by the server rather than being hardcoded in the client application. In this approach:

  1. The server sends a UI description (typically JSON) that defines what components to render and how they should appear
  2. The client interprets this description and dynamically renders the appropriate UI components
  3. The server can change the UI without requiring client-side updates

This differs from traditional approaches where the client application contains hardcoded UI layouts and only requests data to populate them.

Why Use Server-Driven UI?

Server-Driven UI offers several compelling advantages:

1. Consistent Cross-Platform Experience

With SDUI, the same server can deliver optimized UI components for different platforms (web, iOS, Android), ensuring consistent experiences while respecting platform-specific design guidelines.

2. Rapid Iterations Without App Updates

Product teams can experiment with UI changes, launch new features, or fix UI issues by updating the server responses without waiting for app store approvals or client updates.

3. Dynamic Content Presentation

SDUI makes it easy to display personalized content layouts based on user preferences, A/B testing, location, or other contextual factors.

4. Reduced Client Complexity

The client becomes a "UI renderer" that follows server instructions, simplifying client-side code and reducing the need for frequent client updates.

5. Better Resource Management

SDUI allows for careful control over performance-critical aspects like image loading, component reuse, and layout optimizations.

Results

BookMyShow Web and Mobile vs My Recreation (Server-Driven UI)

1. Web View

Original

BookMyShow Web

Recreation

Decoded BMS Web

2. Mobile View – Page 1

Original

BookMyShow Mobile 1

Recreation

Decoded BMS Mobile 1

3. Mobile View – Page 2

Original

BookMyShow Mobile 2

Recreation

Decoded BMS Mobile 2

How I Built a Server-Driven UI Framework

After analyzing BookMyShow's API responses, I identified that they use a component-based SDUI system with various widget types. Let me walk through how I implemented each component type in my framework.

Core Architecture

My approach was to build a component system where each server-defined "type" maps to a React component that knows how to render itself. The central idea is:

  1. Receive widget definitions from the server
  2. Match each widget with its corresponding component based on "type"
  3. Apply styling based on referenced "styleId" values
  4. Recursively render nested components

Widget Types Implementation

1. Card

The Card component is one of the most versatile elements in the system, supporting both vertical and horizontal orientations through a single component implementation. The orientation is determined by the type property in the API response:

// Vertical card example
{
  "id": "EG00418338",
  "type": "vertical",
  "styleId": "5207475275481226612",
  "ctaUrl": "https://in.bookmyshow.com/bengaluru/movies/vidyapati/ET00420153",
  "text": [
    {
      "maxLines": 2,
      "styleId": "7785389241114011138",
      "components": [
        {
          "type": "text",
          "text": "Vidyapati"
        }
      ]
    }
  ],
  "image": {
    "url": "https://assets-in.bmscdn.com/discovery-catalog/events/tr:w-400,h-600,bg-CCCCCC/et00420153-uupnwlhcxm-portrait.jpg",
    "altText": "Vidyapati"
  },
  "tags": [
    {
      "styleId": "2759634946264020090",
      "label": {
        "maxLines": 1,
        "styleId": "-1591248389725590333",
        "components": [
          {
            "type": "text",
            "text": "PROMOTED"
          }
        ]
      }
    }
  ]
}
// Horizontal card example
{
  "id": "EG00420522",
  "type": "horizontal",
  "styleId": "6034184666535124515",
  "ctaUrl": "https://in.bookmyshow.com/bengaluru/movies/the-brutalist/ET00422382",
  "text": [
    {
      "maxLines": 2,
      "styleId": "-6553488546853243560",
      "components": [
        {
          "type": "text",
          "text": "The Brutalist"
        }
      ]
    },
    {
      "maxLines": 2,
      "styleId": "8335147091351660677",
      "components": [
        {
          "type": "text",
          "text": "3h 34m • Drama, Historical • A"
        }
      ]
    }
  ],
  "image": {
    "url": "https://assets-in.bmscdn.com/discovery-catalog/events/tr:w-400,h-600,bg-CCCCCC:l-image,i-discovery-catalog@@icons@@bms_premiere_v1.png,t-false,lfo-bottom_left,l-end/et00422382-tlrwuczldt-portrait.jpg",
    "altText": "The Brutalist"
  },
  "buttons": [
    {
      "styleId": "4132622510035248234",
      "label": {
        "maxLines": 1,
        "styleId": "-3341313454232951668",
        "components": [
          {
            "type": "text",
            "text": "Buy or Rent"
          }
        ]
      },
      "ctaUrl": "https://in.bookmyshow.com/bengaluru/movies/the-brutalist/ET00422382"
    }
  ]
}

My Card component implementation:

  1. Uses a single component that handles both vertical and horizontal types
  2. Dynamically applies different layouts and styling based on the type
  3. Renders common elements like images, text, tags, and buttons
  4. Maintains proper aspect ratios and responsive behavior
  5. Handles navigation through the provided ctaUrl

This approach simplifies the component hierarchy while maintaining flexibility. The component internally determines the appropriate layout and styling based on the type field, which allows for:

The same Card component can appear in various container widgets like Flexbox, HorizontalScroll, and Carousel, making it one of the most frequently used components in the system.

2. Flexbox

Flexbox is a fundamental layout widget that arranges items in rows or columns with specified spacing. Here's an example response:

{
  "id": "TVOD_SHOWCASE_BANNER",
  "type": "flexbox",
  "isSticky": false,
  "styleId": "5330088296335279945",
  "itemsPerRow": 1,
  "horizontalSpacing": 8,
  "verticalSpacing": 8,
  "matchMaxCardHeight": true,
  "cards": [
    {
      "id": "520cc685-544b-403e-a250-847670670f25",
      "type": "vertical",
      "styleId": "-4278837926783854781",
      "ctaUrl": "https://in.bookmyshow.com/explore/c/stream",
      "image": {
        "url": "https://assets-in.bmscdn.com/discovery-catalog/collections/tr:w-1440,h-480:w-600/stream-showcase-banner-exp-collection-202406050332.gif",
        "altText": "Stream"
      }
    }
  ]
}

I implemented a generic Flexbox component that:

  1. Creates a responsive grid layout using CSS flexbox
  2. Applies spacing based on server-provided values
  3. Maintains consistent card heights when specified
  4. Renders child components based on their individual types

The component processes the provided styling information from the referenced styleId to maintain visual consistency with the BookMyShow app.

3. Horizontal Scroll

This widget creates a horizontally scrollable row of content, often used for movie recommendations, categories, or featured content:

{
  "id": "TOP_MOVIES_MOBILE",
  "type": "horizontal-scroll",
  "isSticky": false,
  "styleId": "5340090739233308580",
  "visibleItems": 2.75,
  "itemsPerRow": 10,
  "horizontalSpacing": 8,
  "verticalSpacing": 0,
  "title": {
    "maxLines": 1,
    "styleId": "7987316217275958678",
    "components": [
      {
        "type": "text",
        "text": "Recommended Movies"
      }
    ]
  },
  "matchMaxCardHeight": true,
  "cta": {
    "label": {
      "components": [
        {
          "type": "text",
          "text": "See All ›"
        }
      ]
    },
    "url": "https://in.bookmyshow.com/explore/movies-bengaluru"
  },
  "cards": [
    /* movie cards here */
  ]
}

My HorizontalScroll component includes:

  1. A container with overflow handling for horizontal scrolling
  2. Customizable item widths based on the visibleItems property
  3. Optional title and "See All" CTA rendering
  4. Proper spacing and alignment of cards
  5. Touch-friendly scrolling behavior with momentum

This component is particularly useful for browsing through collections of similarly formatted content items.

The carousel widget presents a full-width slideshow of content, typically used for featured content or promotions:

{
  "id": "TVOD_SHOWCASE",
  "type": "carousel",
  "isSticky": false,
  "styleId": "8429547327424683329",
  "horizontalSpacing": 16,
  "title": {
    "maxLines": 1,
    "styleId": "-4509315044828611300",
    "components": [
      {
        "type": "text",
        "text": "Watch Top Movies Online"
      }
    ]
  },
  "subtitle": {
    "maxLines": 1,
    "styleId": "-5103615806931264414",
    "components": [
      {
        "type": "text",
        "text": "Buy or Rent movies on BMS STREAM"
      }
    ]
  },
  "matchMaxCardHeight": false,
  "cards": [
    /* movie cards here */
  ],
  "snapping": false,
  "fillViewport": false,
  "immersive": false,
  "minPeek": 0,
  "autoScrollDuration": 3000,
  "showIndicators": true,
  "sliderDuration": 3000
}

My Carousel component features:

  1. Auto-advancing slides with configurable timing
  2. Interactive navigation indicators
  3. Optional title and subtitle sections
  4. Support for different card types within the carousel
  5. Touch-friendly swipe gestures

The flexibility of this component allows it to showcase anything from promotional banners to curated content collections.

5. Advertisement

The advertisement widget is a specialized component for handling dynamic ad content:

{
  "id": "AD_HOME_CAROUSEL_MWEB",
  "adtechId": "AD_HOME_CAROUSEL",
  "type": "advertisement",
  "isSticky": false,
  "styleId": "-4248498540950589586",
  "matchMaxCardHeight": false,
  "cards": [
    {
      "adtype": "DISPLAY",
      "reqid": "7577a3b7-755c-42db-95f2-7b92c85627a5",
      "adunitcode": "homepage_carousel3_mweb",
      "size": "SIZE_FLUID",
      "assets": {
        "adm": "<!-- HTML Ad Content -->",
        "duration": 3000,
        "iurl": "https://adtech-events.bookmyshow.com/adevent/v2/imp?reqid=7577a3b7-755c-42db-95f2-7b92c85627a5",
        "position": 3
      }
    }
  ]
}

This component required special handling:

  1. The initial API response includes the advertisement container but not the actual ad content
  2. A separate API call fetches the ad content
  3. I merge both responses to create a complete advertisement widget
  4. For multiple ads, I render them as a carousel
  5. For single ads, I render them directly

6. Mobile Bottom Navigation

This specialized navigation component defines the app's main navigation structure:

{
  "defaultSelected": "home",
  "bgColor": "#FFFFFF",
  "tabs": [
    {
      "id": "home",
      "icon": {
        "defaultUrl": "https://assets-in.bmscdn.com/discovery-catalog/collections/home-default-collection-202302270255.png",
        "selectedUrl": "https://assets-in.bmscdn.com/discovery-catalog/collections/home-selected-collection-202302270255.png"
      },
      "label": {
        "text": "Home",
        "color": "#666666"
      },
      "cta": {
        "type": "embed",
        "url": "https://in.bookmyshow.com/explore/home/"
      },
      "header": {
        /* header configuration */
      }
    }
    /* other tabs */
  ]
}

My BottomNavigation component:

  1. Renders a fixed-position navigation bar at the bottom of the screen on mobile
  2. Tracks the currently selected tab with appropriate visual indicators
  3. Applies the appropriate header configuration for each tab

This component serves as the primary navigation structure on mobile, demonstrating how even core interface elements can be server-driven.

Style Management

A key aspect of the SDUI system is the style handling. BookMyShow's API includes style definitions referenced by styleId:

{
  "id": "-130514066956528765",
  "aspectRatio": 12,
  "padding": "40,0,40,0",
  "type": "widget",
  "shimmer": false,
  "imageVerticalAlignment": "bottom"
},
{
  "id": "1013830832253216626",
  "padding": "0,0,32,0",
  "type": "widget",
  "headerContainer": {
    "padding": "0,0,0,0",
    "margin": "0,0,8,0"
  },
  "cardsContainer": {
    "padding": "0,0,0,0"
  }
}

My approach to style handling:

  1. When rendering components, look up the appropriate style by styleId
  2. Transform server-style values into CSS-compatible properties
  3. Apply styles using CSS-in-JS or styled-components
  4. Implement fallback styling for unknown styleId values

This approach allows for consistent application of styles while maintaining the flexibility of server-driven configurations.

Challenges and Learnings

Building this SDUI framework presented several interesting challenges:

1. Component Hierarchy and Nesting

Handling deeply nested components while ensuring proper props propagation was complex. I implemented a recursive rendering system that could handle arbitrary nesting levels.

2. Style Interpretation

Converting the server's style definitions into CSS required careful parsing and transformation. Special handling was needed for different units, property names, and platform-specific style values.

3. Error Handling and Fallbacks

When server responses contain unexpected or malformed data, graceful degradation is essential. I built in fallback rendering options and error boundaries to prevent complete UI failures.

Conclusion

Server-Driven UI represents a powerful pattern for building flexible, maintainable applications. By studying and implementing BookMyShow's approach, I've created a framework that demonstrates the benefits of this architecture.

The Decode BookMyShow project is now available on GitHub as an open-source reference implementation. Whether you're building a new application or considering transitioning to SDUI, I hope this project provides valuable insights into how large-scale applications implement this pattern effectively.

Feel free to explore the code, contribute improvements, or adapt the concepts for your own projects!
